DTB10/10 Differential pressure transmitter for air and non-corrosive gases with display
Differential pressure transmitter with display and -100…+100 Pa measuring range
Specifications
| Sensor Interface | 0-10 V, 4-20 mA |
|---|---|
| Display | Yes |
| Display | Yes |
| Display type | LED, 4 digits |
| Analogue output load impedance 0...10v | ≥ 1 kΩ |
| Analogue output load impedance 4...20mA | 20…500 Ω |
| Pressure, range sensor | -100…100 Pa |
| Accuracy, pressure sensor 1 | ±1 % full scale, min. ±1 Pa % |
| Max. allowed diff. Pressure sensor 1 | 60 kPa |
| Power Supply | 24VAC/DC (18...30 V AC 50Hz / 18...30 V DC), 6.0 VA |
|---|---|
| Protection class | IP54 |
| Ambient humidity (non-condensing) | 0…95 % RH |
| Ambient temperature | -10…50 °C |
| Storage temperature | -10…50 °C |
| Mounting | Wall |
| Dimensions, external (WxHxD) | 85x85x58 mm |
| Weight, incl. packaging | 0.18 kg |
| Media | Air and non-corrosive gases |
| Cable gland | M16x1,5 |
| Terminal type | Screw Terminal |
| Terminal wire size | 1.5 mm² |
| Material, housing | ABS |
