Specifications
Pressure rating | PN16 |
---|---|
Connection | Flanges according to SS 335 table 6 |
Flow characteristics | Equal percentage |
Max. leakage | 0.1 % of kvs |
Media temperature | -5...+185°C |
Media | Hot, cold, glycol-mixed water or steam |
Rangeability | 50:1 |
Max. diff. pressure | 1600kPa |
Body | Nodular cast iron Grade 500/7 |
Seat | Stainless steel 304S15 |
Plug | Stainless steel 303S31 |
Stem | Stainless steel 303S31 |
Lining | Stainless steel 304S15 |
Packing box | Dezincification resistant brass CW 602N, self-adjusting teflon (o-ring viton) |
O-rings | Viton |
Software & documentation
Product sheet
Accessories
S0603080300
Spare parts kit, packing box for ETRS, MTVS and MTRS valves (until 2019-12), for ETVS valves (until 2021-04)…
