DP156NX 15.6” panel PC for control panel mounting
15.6" Panel PC
Navigate on this page
Specifications
| Supply voltage | 9…36 V DC |
|---|---|
| CPU type | Intel Quad Core J1900 2.0 GHz (fanless) |
| RAM | 8 GB DDR3L SDRAM |
| Screen size | 15.6" |
| Resolution | 1366 x 768 pixels |
| Operating system | Windows 10 IoT Enterprise |
| Mounting | Panel mount |
| Protection class, front | IP65 |
| Protection class, back | IP20 |
| Connections | 1 x RS485/RS232 1 x RS232 2 x 10/100/1000 Mbit Ethernet 2 x USB A 1 x 3.5 mm Audio out 1 x VGA 1 x HDMI |
