Regin
HMH Duct/wall humidistat.
Duct/wall humidistat
Specifications
| Dimensions, external (WxHxD) | 104x98x74 mm |
|---|---|
| Medium | Air/Gas |
| Mounting | Wall/(Room) |
| Reset function | Automatic |
| Conformity | CE |
| Contact type | 1 step, change-over contact, NO/NC, Not suitable for DC circuits |
| Switching load | 10 A, 250 VAC resistive at 25 °C ambient 8 A, 250 VAC resistive at 60 °C ambient |
| Electrical connection | Screw terminal |
| Cable inlet | PG11, cable Ø6 - 10mm |
| Sensitive element | Organic fiber (hygroscopic hair type) |
| Measuring range, humidity | 10…100 %RH |
| Hysterisis, humidity | 3% RH @45% RH |
| Appliance class | Class I |
|---|---|
| Protection class | IP54 |
| Mounting | Wall |
| Bulb length | 222 mm |
| Bulb diameter | 35 mm |
| Weight, incl. packaging | 0.6 kg |
| Material, cover | Polycarbonate (PC) |
| Material, base | Extruded aluminum (grey) |
