TCP/IP

This product is discontinued

Articles

(0 st)

Specifications for TCP/IP
Supply voltage	24 V AC ±15 %, 50...60 Hz or 20...36 V DC
Power consumption	5 VA
Display	Backlit, LCD, 4 rows of 20 characters, international character set
Dimensions (WxHxD)	148 x 123 x 58 mm, 8.5 modulesmm
Protection class	IP20
Mounting	DIN-rail or cabinet
Analogue inputs (AI)	0...10 V DC, 0...200 mV, PT1000, DIN Ni1000, LGNi1000, 12-bit A/D
Digital inputs (DI)	Floating switch, 24 V DC, configurable for pulse input
Universal inputs (UI)	AI or DI (see above)
Analogue outputs (AO)	0...10 V DC, 5 mA, 8-bit D/A, short-circuit proof
Digital outputs (DO)	Mosfet 24 V AC/DC, 2 A. Totally max. 8 A.
24 V DC output	0.1 A, short-circuit proof
Communication	EXOline, Modbus or dial-up connection Port 1, isolated, via a built-in RS485 connector. Modems are available as accessories for Port 1. There are models with TCP/IP or LON communication.
Operating system	EXOreal
Battery backup	Memory and real-time clock, at least 5 years
LON	FT3150, gives a second communication route
Ethernet	EXOline (Port 1) over TCP/IP instead of RS485
